Gabbro

Gabbro

Image: Anne Burgess (<a rel="nofollow" class="external free" href="https://www.geograph.org.uk/profile/139">https://www.geograph.org.uk/profile/139</a>) (CC BY-SA 2.0)

Mineral NameGabbro
Chemical FormulaPrimarily composed of calcic plagioclase feldspar and pyroxene (augite), with minor olivine and amphibole.
Mohs Hardness6
Streak ColorGrayish-white to dark gray
CleavageGood in constituent minerals (plagioclase and pyroxene)
FractureUneven to conchoidal
Specific Gravity2.8
Colorsdark gray, black, greenish-black, brownish-gray (weathered)
TransparencyOpaque
Type LocalityArdnamurchan, Scotland
Mineral GroupIgneous Rock (Plutonic, Mafic)
Usesconstruction aggregate, dimension stone, ornamental stone
Associated Mineralsplagioclase feldspar, pyroxene (augite), olivine, hornblende, magnetite
Raritycommon

Description

The image displays a large outcrop of gabbro, a coarse-grained igneous rock, exhibiting prominent modal layering with alternating bands of lighter and darker minerals, appearing brownish-gray due to weathering.

Geological Context

Gabbro is a coarse-grained, intrusive igneous rock that forms from the slow crystallization of mafic magma deep beneath the Earth's surface in magma chambers. The distinct layering observed in this example is a result of crystal settling, where heavier minerals crystallize and accumulate at the bottom of the magma chamber. This specific occurrence is associated with the Paleogene volcanism of Scotland.
